The operation of a DC motor is dependent on the workings of the poles of the stator with a part of the rotor, or armature. The stator contains an even number of poles of alternating magnetic polarity, each pole consisting of an electromagnet formed from a pole winding wrapped around a pole core. When a DC current flows through the winding, a.. In a motor, the wire is wound around a central block. called an armature. A spindle through the armature allows it to rotate. The current flows in opposite directions on each side. of the armature, so one side is pushed while. the other is pulled . This makes the armature rotate. After the armature has rotated through half a turn ( 180 ° ),
