Here are two wiring diagrams for the 7 pin 'N' type trailer electrical plug. The first diagram is a simple set up of two brake lights, two indicators and two side lights. Click on the image below to enlarge it. The second diagram shows two brake lights, two indicators, two side lights and a fog light. Click on the image below to enlarge it.. A colour coded trailer plug wiring guide to help you require your plugs and sockets. Includes guides for 7 pin, 6pin, 5 pin, 12 pin, 13 pin, pin and heavy duty round plugs and sockets.. and Sockets. Narva 7 and 12 pin trailer connectors comply with all relevant ADRs. Flat connectors comply with Australian Standards AS4177.5-2004.
